Sheathing Bridge

Our highest capacity fully automated sheathing bridge allows for up to 8 Continuum Dual Coil Articulating Nail Heads on a single rail. These 6" narrow nail heads maximum flexibility for dividing up the nailing workload across all guns. Screw gun, stapler, saw, and router tooling can be added with additional heads or piggybacked to existing heads on either side of this bridge designed for wood or light frame steel construction

HyperLeap Sheathing Bridge robotic automation system

The Fastest and most Versatile Sheathing Bridge available.

Continuum Dual Coil Articulating Nails Heads switch between 2 nail coils without breaking stride, allowing for simultaneous reloading of coils on multiple heads which increases uptime. A centering tilt mechanism eliminates x-axis bridge movement on seams while dual lasers continually adjust for variations in panel thickness to provide consistent nail embedment. Oversized Tall Walls, Rake Walls, and Floor Cassettes can be sheathed when turned 90 degrees allowing the Sheathing Bridge to auto fasten those products as well. The HyperLeap Sheathing Bridge to auto fasthen those products as well. The HyperLeap Sheathing Bridge combined with an Datum Squaring Table equipped with Atlas Two Stage Squaring and WarpDrive Multi Panel Staging significantly increases the speed of your sheathing station. Eliminate the sheathing bottleneck and speed up your whole production line while freeing up your operators for value added tasks.

PRODUCT SPECS

Integration with the Datum Squaring Tables with WarpDrive Multi Panel Staging System and Atlas Two Stage Squaring for maximum throughput
Continuum Dual Coil Articulating Nail Heads with Multi Tooling Support. 6" narrow profile allows room to add additional tooling on a single head.
Continuum Centering Tilt Mechanism for fastening vertical seams without an X-axis move to auto tilt for horizontal seams.
Continuum Nail Head Dual Laser precisely measure the surface of the panel for consistent nail embdedment.
FlowState Optimizing enables all heads to share work equally while taking advantage of their 6" narrow profile - no heads are dedicated to top and bottom plates.
Multiple heads can fit above or below openings. Panels are fastened in one direction, allowing a speedy return while the current panel is ejected and the next panel is positioned and squared. Alternatively, other value added tasks can be performed while returning to the home position.
Programmable Park and Reload locations (separate from the Home position).
Cloud based software for Error Reporting, Production Statistics, Preventative Maintenance and Remote Monitoring and Diagnosis.
Special nailing zones on panels specified by Designers or Production Management.
1-8 Nailing Heads with options to add additional heads or piggyback more tooling at a later date.
Tooling for industrial screw systems, routers, saws, glue heads, lasers available.
Compatible with the AMT Multiverse Panel Flipping and Material Handling Station.
Standard work area 14' width × 20' length × 18" depth; custom sizes are available up to 30' wide, 48' long, and 24" deep. 14' width allows 1' overhang on both the top and bottom of a 12' panel for attaching to adjacent rim board on site.
Heavy duty construction with powder coated finish.
Back side of bridge is available for additional functionality.
3 year warranty

For personalized configurations, please reach out to our representatives.
