Sheathing Bridge
Our lower cost but still fully automated sheathing bridge allows for up to 4 Single Coil Articulating Nail Heads on the same side of the bridge allowing the fastening workload to be divided equally. The result is a bridge that can produce panels faster than other brands with 6 head bridges. Screw gun, stapler, saw, and router tooling can be added with additional heads or piggybacked to existing heads on either side of this bridge designed for wood or light frame steel construction.
Nearly the Same Nailing Speed with a Lower Upfront Cost
Centering tilt mechanisms eliminate x-axis bridge movement on seams while dual lasers continually adjust for variations in panel thickness to provide consistent nail embedment. Tall Walls, Rake Walls and Floor Cassettes can be sheathed when turned 90 degrees allowing the Sheathing Bridge to auto fasten those products as well. The ForwardLeap Sheathing Bridge combined with an Datum Squaring Table equipped with Atlas Two Stage Squaring and WarpDrive Multi Panel Staging significantly increases the speed of your sheathing station. Eliminate the sheathing bottleneck and speed up your whole production line while freeing up your operators for more value added tasks. To minimize nail reload interruptions, fit more nail heads into spaces above and below rough openings, or add up to 8 Nail Heads consider upgrading to the industry leading AMT HyperLeap Sheathing Bridge with 6" wide Continuum Dual Coil Nail Heads.
PRODUCT SPECS
-
Integration with the Datum Squaring Tables with the WarpDrive Multi Panel Staging System and Atlas Two Stage Squaring for maximum throughput.
-
Single Coil Articulating Nail Heads with Multi Tooling Support. 7” width, with up to 4 heads located on the same side of the bridge.
-
Centering Tilt Mechanism for fastening vertical seams without an X-axis move and auto tilt for horizontal seams.
-
Dual Lasers on each head precisely measure the surface of the panel for consistent nail embedment.
-
FlowState Optimizing enables all heads to share work equally while taking advantage of their 7” narrow profile - no heads are dedicated to top and bottom plates. Multiple heads can fit above or below openings. Panels can be fastened in one direction, allowing a speedy return while the current panel is ejected and the next panel is posifioned and squared. Alternatively, other value added tasks can be performed while returning to the home position.
-
Programmable Park and Reload locations (separate from the Home position).
-
Cloud software for Error Reporting, Production Statistics, Preventative Maintenance and Remote Monitoring and Diagnosis.
-
Special nailing zones on panels specified by Designers or Production Management.
-
1-4 Nailing Heads with options to add addifional heads or other tooling on the other side of the bridge at a later date.
-
Tooling for industrial screw guns, staplers, routers, and saws available.
-
Compatible with the AMT Multiverse Panel Flipping and Material Handling Station.
-
Standard work area 14’ width x 20’ length x 18” depth; custom sizes are available up to 16' wide, 48’ long, and 24” deep. 14’ width allows 1’ overhang on both the top and bottom of a 12’ panel for attaching to adjacent rim board on site.
-
Heavy duty construction with powder coated finish.
-
Back side of bridge is available for additional functionality.
-
3 year warranty
